Mini Wireless Zigbee Gateway

Intelligent and elegant Zigbee gateway with a long range coverage. It integrates with your smart speakers and you can control all your devices by voice or from your smartphone.

TUYA Zigbee hub that connects to a variety of Zigbee smart products and is the bridge and control center for smart homes. By connecting to the router, TYGWZ-01 enables communication with the cloud and mobile app, allowing users to easily view and control various smart devices in the home that use the Zigbee protocol.

Parameter:

- Chip: EFR32MG1B232

- Standard: IEEE 802.15.4

- Frequency: 2.4~2.485GHz

- Maximum output power: 19dBm

- Dynamic output power: >35dB

- Open line of sight transmission distance: >300m

- Frequency error: ±15ppm

- Theoretical transmission rate: 250kbps

- Receive sensitivity: typical -102dBm, PER<10%

- Total number of channels: 16 Channel number: 11~26

- Network topology: Supports star, tree, mesh network

- Antenna: default PCB onboard antenna Firmware upgrade: Support OTA

Electrical Specification

- Working voltage: 1.8V ~ 3.3V

- Working temperature: -10-55°C

- Working humidity: 10%-90%RH (non-condensing)

- Storage temperature: -20-60°C

- Storage humidity: 5%-90% RH (non-condensing)
